2022金砖国家工业创新大赛

入围决赛项目信息

一、参赛项目名称（中文）

世界首台700MW双水内冷汽轮发电机的研究与应用

二、参赛项目名称（英文）

Research and Application of the World's First 700MW Double-Water Internal Cooling Turbogenerator.

三、参赛单位（中文）

京能（锡林郭勒）发电有限公司

四、参赛单位（英文）

Jingneng（XilinGuole）Power.Co.,Ltd.

五、项目简介（中文）

世界首台700MW级双水内冷汽轮发电机究项与项目从2020年1月开始。在首台660MW级双水内冷发电机成功运行经验基础上，结合实际运行工况，联合上海发电机厂对发电机组设备现场运行状态进行评估。经过空气冷却器、转子水冷却器增容，优化集电环结构以及通过发电机700MW工况下的励磁系统模型参数测试、PSS试验、一次调频试验、进相试验、温升试验、锅炉的效率和最大出力试验、汽轮机性能试验、汽轮机及其调速系统参数测试验以及整个机组AGC、AVC试验和VWO工况试验，论证了700MW双水内冷汽轮发电机的技术线路具有合理性，能够满足当前双水内冷汽轮发电机的运行要求。在试验过程中，通过对其运行边界条件的优化以及试验，得到了700MW双水内冷汽轮发电机中各项设备技术指标的参数。效率试验证明该双水内冷汽轮发电机700MW时效率高达99.04%。发电机700MW增容提效研究成功，为更大单机容量的双水内冷发电机的研发制造提供参考，进而以相关的运行参数为基础，有效实现发电机结构的改良优化，为相关领域的工业化发展奠定基础。为我国自主研发的双水内冷发电机的大容量发展提供成功案例，推动国产重大设备的研究和发展，开启大型发电机的无氢化、经济化的新市场和新潮流，引领技术发展方向的变革。

六、项目简介（英文）

The world's first 700MW double-water internal cooling turbogenerator project began in January 2020. Based on the successfully operation of the world's first 660MW double-water internal cooling generator, we—together with Shanghai power plant—evaluated the on-site operating status of the 700MW double-water internal cooling turbogenerator unit equipment. Under 700MW working condition, the generator has passed the excitation system model parameter test, PSS test, primary frequency modulation test, phase advance test, temperature rise test, boiler efficiency and maximum output test, steam turbine performance test, steam turbine and its speed control system parameter test, AGC, AVC test and VWO working condition test of the whole unit. It is proved that the technical circuit of 700MW double-water internal cooling turbogenerator is reasonable and meet the operation requirements of the current double water internal cooling turbo generator. During the test, we optimized the operating boundary conditions, and found the technical parameters of the equipment in the 700MW double-water internal cooling turbogenerator. The efficiency is as high as 99.04% in the efficiency test. The successful study on capacity increase and efficiency improvement of 700MW generator provides a reference for the R & D and manufacturing of double water internal cooling generator with larger single unit capacity. With the relevant operating parameters, the generator structure can be optimized effectively, which laying a foundation for the industrial development of relevant fields. By providing the successful case for the large-capacity development of the self-developed double water internal cooling generator in China, it promotes the research and development of domestic major equipment, opens a new market and new trend of hydrogenation free and economical large-scale generators, and leads the change in the direction of technological development.

七、展示图片
